SolarEdge P505 Power Optimizer

Module-Level Power Electronics (MLPE) for SolarEdge systems
$949 (per unit, bulk discounts available)

Key Features

  • Maximizes energy production from each solar panel
  • Module-level monitoring capabilities
  • Safety: Rapid shutdown compliant (NEC 2017/2020)
  • Weatherproof design (IP68 rated)
  • 25-year warranty
  • Easy installation with plug-and-play connectors
  • Model: P505
  • Maximum Input Power: 505W
  • Maximum Input Voltage: 60V
  • Output Voltage Range: 8-60V
  • Maximum Output Current: 15A
  • Peak Efficiency: 99.5%
  • Weight: 1.8 lbs (0.82 kg)
  • Dimensions: 6.3 x 4.1 x 1.2 in (160 x 104 x 30 mm)
  • Operating Temperature: -40°C to 65°C (-40°F to 149°F)
  • Ingress Protection: IP68 (Water and dust proof)
  • Warranty: 25 years

Compatible With

  • All SolarEdge inverters (HD-Wave, SE, StorEdge)
  • Solar panels up to 505W
  • Monocrystalline and polycrystalline panels
  • 60-cell, 72-cell, and half-cut modules
  • Bifacial solar panels
  • Thin-film panels (with voltage matching)

Not Recommended For

  • Panels over 505W (use P730 model instead)
  • Non-SolarEdge system architectures

Installation Overview

The P505 optimizer is installed underneath each solar panel, typically mounted to the racking system. Installation requires:

  • DC wiring between panel and optimizer
  • Connection to SolarEdge inverter system
  • Commissioning via SolarEdge monitoring platform

Typical Installation Time

5-10 minutes per optimizer for experienced installers

Tools Required

  • #2 Phillips screwdriver
  • Wire cutters/strippers
  • Multimeter
  • SolarEdge commissioning tool (recommended)

25-Year Limited Warranty

SolarEdge warrants the P505 Power Optimizer against defects in materials and workmanship for 25 years from the date of purchase.

Coverage Includes

  • Repair or replacement of defective units
  • Performance guarantee (98% efficiency for 25 years)
  • Protection against environmental failures

Warranty Registration

Must be registered within 90 days of installation via SolarEdge website to activate coverage.
